Europull Electrical Chain Hoist
High-performance Europull EPC electrical chain hoist with integrated load limiter. Available in 3-Phase 380V & 415V 50/60Hz, featuring dual lifting speeds, electromagnetic disc brake, and heavy-duty IP55 motor.
- Capacity0.5t - 5t
- Power3-Phase 380V/415V 50/60Hz
Need sizing help? Email info@europull.com
- Certified to EN 14492-2 / CE
- 5 models available
Technical Specifications
Model-by-model data for the Europull Electrical Chain Hoist range.
| Model Code | Capacity (Tons) | Speed (m/min) | Motor (kW) | Falls | Chain (mm) | Proof Load (kN) | Net Weight (kg) |
|---|---|---|---|---|---|---|---|
| EPC-E05 | 0.5 Ton (500 kg) | 6.8 / 2.3 | 0.8 kW | 1 | 6.3 mm | 6.25 kN | 52 kg |
| EPC-E10 | 1.0 Ton (1,000 kg) | 6.6 / 2.2 | 1.5 kW | 1 | 7.1 mm | 12.5 kN | 65 kg |
| EPC-E20 | 2.0 Ton (2,000 kg) | 5.4 / 1.8 | 3.0 kW | 2 | 7.1 mm | 25.0 kN | 88 kg |
| EPC-E30 | 3.0 Ton (3,000 kg) | 4.4 / 1.5 | 3.0 kW | 2 | 10.0 mm | 37.5 kN | 115 kg |
| EPC-E50 | 5.0 Ton (5,000 kg) | 2.8 / 0.9 | 3.0 kW | 2 | 11.2 mm | 62.5 kN | 168 kg |
Need a model or configuration not listed? Email our engineering team or download the full catalog (PDF).
Key Parameters
| Parameter | Specification | Highlight |
|---|---|---|
| Standard / Norms | EN 14492-2 / CE Directive 2006/42/EC | Certified |
| Rated Capacity | 0.5 Ton to 5 Ton | 0.5t - 5t |
| Supply Voltage | 3-Phase 380V / 415V 50/60Hz | Industrial 3P |
| Lifting Speed | Dual Speed (e.g. 6.8 / 2.3 m/min) | Precision Control |
| Motor & Protection | Heavy-Duty Class F Insulation, IP55 Enclosure | Thermal Cut-Out |
| Braking System | Electromagnetic Disc Brake + Mechanical Load Limiter | Instant Stop |
| Pendant Control | Ergonomic Push-Button Control with Emergency Stop | 24V Low Voltage |
Key Features & Advantages
Integrated Load Limiter
Fitted with mechanical slip clutch load limiter to prevent dangerous overloading.
Electromagnetic Safety Brake
Heavy-duty electromagnetic disc brake engages instantly upon power release.
Phase Error Relay
Protects electrical components from incorrect power connection and reverse rotation.
24V Low Voltage Control
Low-voltage pendant station ensures operator safety against electric shocks.
Standards & Compliance
EN 14492-2 Compliance
European standard for power driven hoists.
CE Machinery Directive
2006/42/EC verified with factory test certificate.
Product Overview
The Europull Electric Chain Hoist combines rapid lifting capability with pinpoint positioning accuracy. Built with durable aluminum alloy casing, high-grade helical gearing, and advanced motor cooling fins for high-duty cycle industrial manufacturing and foundry operations.
Frequently Asked Questions
The Europull Electrical Chain Hoist is available in 5 models: EPC-E05, EPC-E10, EPC-E20, EPC-E30, EPC-E50. Capacity (Tons) ranges from 0.5 Ton (500 kg) to 5.0 Ton (5,000 kg). Full figures for every model are in the technical specifications table on this page.
The Europull Electrical Chain Hoist covers 0.5t - 5t.
The Europull Electrical Chain Hoist is manufactured to EN 14492-2 / CE.
The Europull Electrical Chain Hoist's supply Voltage: 3-Phase 380V / 415V 50/60Hz.
The Europull Electrical Chain Hoist's lifting Speed: Dual Speed (e.g. 6.8 / 2.3 m/min).
The Europull Electrical Chain Hoist's motor & Protection: Heavy-Duty Class F Insulation, IP55 Enclosure.
Click "Request a Quote" on this page to add the Electrical Chain Hoist to your quote cart, or email info@europull.com with the model code and quantity you need.
