Europull Manual Lever Hoist
The Europull series manual lever hoist (EPC-L Series) is designed for pulling, lifting, and tensioning at any angle. Ideal for confined spaces, pipe fitting, and structural rigging with a 360° rotating handle and free-chaining neutral mechanism in compliance with EN 13157.
- Capacity0.75t - 9t
- Lift Height1.5m (Custom available)
Need sizing help? Email info@europull.com
- Certified to EN 13157
- 6 models available
Technical Specifications
Model-by-model data for the Europull Manual Lever Hoist range.
| Model Code | Rated Capacity (Tons) | No. of Falls | Chain Dia (mm) | Std Lift (m) | Proof Load (kN) | Lever Pull to WLL | Net Weight (kg) |
|---|---|---|---|---|---|---|---|
| EPC-L075 | 0.75 Ton (750 kg) | 1 | 6 × 18 mm | 1.5 m | 11.25 kN | 148 N | 6.8 kg |
| EPC-L100 | 1.0 Ton (1,000 kg) | 1 | 6 × 18 mm | 1.5 m | 15.0 kN | 196 N | 7.5 kg |
| EPC-L150 | 1.5 Ton (1,500 kg) | 1 | 8 × 24 mm | 1.5 m | 22.5 kN | 220 N | 11.8 kg |
| EPC-L300 | 3.0 Ton (3,000 kg) | 1 | 10 × 30 mm | 1.5 m | 45.0 kN | 320 N | 19.5 kg |
| EPC-L600 | 6.0 Ton (6,000 kg) | 2 | 10 × 30 mm | 1.5 m | 90.0 kN | 340 N | 29.5 kg |
| EPC-L900 | 9.0 Ton (9,000 kg) | 3 | 10 × 30 mm | 1.5 m | 135.0 kN | 360 N | 45.0 kg |
Need a model or configuration not listed? Email our engineering team or download the full catalog (PDF).
Key Parameters
| Parameter | Specification | Highlight |
|---|---|---|
| Standard / Norms | EN 13157 / CE Directive 2006/42/EC | Certified |
| Rated Capacity | 0.75 Ton to 9 Ton | 0.75t - 9t |
| Lever Handle | 360° Full Rotation Handle with Ergonomic Rubber Grip | Confined Space |
| Braking System | Automatic Weston Double-Pawl Mechanical Brake | Fail-Safe |
| Free-Chaining | Neutral Shift Position for Fast Chain Pulling | Quick Rigging |
| Safety Factor | 4:1 Safety Factor (Fatigue tested 1.5x to 2000 cycles) | Proof Tested |
| Load Chain | Grade 80 Galvanized Alloy Steel Chain (EN 818-7) | Calibrated |
Key Features & Advantages
360° Rotating Lever Handle
Facilitates seamless operation in tight, confined spaces and odd rigging angles with minimum operator fatigue.
Free-Chaining Neutral Mechanism
Special separating block design allows the chain to be pulled freely to position the bottom hook when unloaded.
Double-Pawl Weston Brake
Provides instant load holding and controlled lowering with 2x mechanical braking redundancy.
Heat Treated Steel Plates
Side plates, gears, and pinion shafts are heat-treated for extreme structural durability and wear resistance.
Drop-Forged Safety Hooks
Equipped with heavy-duty forged steel safety latches and 360-degree rotation.
High Fatigue Strength
Tested to 1.5 times working load limit for over 2,000 cycles without deformation.
Standards & Compliance
EN 13157 Compliance
European standard for hand-operated lever hoists.
EN 818-7 Grade 80
Calibrated alloy load chain with galvanized finish.
CE Directive 2006/42/EC
Certified European machinery safety.
1.5x Proof Load Tested
Factory load tested with individual certificate.
Product Overview
The Europull Manual Lever Hoist (EPC-L series) is an indispensable tool for heavy rigging, pipe alignment, machinery installation, and structural dragging across construction, boat manufacturing, mining, and oilfield sites. Compact yet exceptionally robust, its lightweight design allows easy transport and single-operator handling. The free-chaining neutral mechanism enables rapid hook positioning without tension, while the Weston double-pawl brake ensures absolute load security under all working angles.
Frequently Asked Questions
The Europull Manual Lever Hoist is available in 6 models: EPC-L075, EPC-L100, EPC-L150, EPC-L300, EPC-L600, EPC-L900. Rated Capacity (Tons) ranges from 0.75 Ton (750 kg) to 9.0 Ton (9,000 kg). Full figures for every model are in the technical specifications table on this page.
The Europull Manual Lever Hoist covers 0.75t - 9t.
The Europull Manual Lever Hoist is manufactured to EN 13157.
The Europull Manual Lever Hoist's lever Handle: 360° Full Rotation Handle with Ergonomic Rubber Grip.
The Europull Manual Lever Hoist's braking System: Automatic Weston Double-Pawl Mechanical Brake.
The Europull Manual Lever Hoist's free-Chaining: Neutral Shift Position for Fast Chain Pulling.
Click "Request a Quote" on this page to add the Manual Lever Hoist to your quote cart, or email info@europull.com with the model code and quantity you need.
