Europull Electrical Winch
Heavy-duty electric winch built for demanding pulling and hoisting applications in industrial construction, mining, shipyards, and offshore installations.
- Capacity500kg - 10,000kg
- PowerElectric 3-Phase 380V/415V
Need sizing help? Email info@europull.com
- Certified to EN 14492-1 / CE
- 5 models available
Technical Specifications
Model-by-model data for the Europull Electrical Winch range.
| Model | Capacity (kg) | Rope Speed (m/min) | Motor (kW) | Rope Dia (mm) | Drum Cap (m) | Weight (kg) |
|---|---|---|---|---|---|---|
| EP-EW05 | 500 kg | 15 m/min | 1.5 kW | 8 mm | 60 m | 68 kg |
| EP-EW10 | 1,000 kg | 15 m/min | 3.0 kW | 11 mm | 80 m | 115 kg |
| EP-EW20 | 2,000 kg | 12 m/min | 5.5 kW | 14 mm | 100 m | 185 kg |
| EP-EW50 | 5,000 kg | 10 m/min | 11.0 kW | 20 mm | 120 m | 360 kg |
| EP-EW100 | 10,000 kg | 8 m/min | 18.5 kW | 28 mm | 150 m | 720 kg |
Need a model or configuration not listed? Email our engineering team or download the full catalog (PDF).
Key Parameters
| Parameter | Specification | Highlight |
|---|---|---|
| Standard / Norms | EN 14492-1 / CE Certified | Certified |
| Rated Capacity | 500 kg to 10,000 kg | 0.5t - 10t |
| Motor & Voltage | Heavy-Duty Induction Motor 380V/415V 3-Phase | IP55 |
| Brake System | Fail-Safe Electromagnetic Drum / Disc Brake | Instant Stop |
| Drum Capacity | Heavy Gauge Steel Drum for 30m - 150m Wire Rope | Grooved Drum |
| Control | IP65 Pendant Control Station with Emergency Stop | Low Voltage 24V |
Key Features & Advantages
High Strength Grooved Drum
Maintains orderly spooling of wire rope to eliminate bunching and surface abrasion.
Electromagnetic Fail-Safe Brake
Holds the maximum rated load securely during power interruptions.
Standards & Compliance
EN 14492-1
Power driven winches standard.
CE Certified
Factory load tested.
Product Overview
Delivers continuous pulling and lifting force for marine slipways, quarry operations, construction hoists, and heavy structural positioning.
Frequently Asked Questions
The Europull Electrical Winch is available in 5 models: EP-EW05, EP-EW10, EP-EW20, EP-EW50, EP-EW100. Capacity (kg) ranges from 500 kg to 10,000 kg. Full figures for every model are in the technical specifications table on this page.
The Europull Electrical Winch covers 500kg - 10,000kg.
The Europull Electrical Winch is manufactured to EN 14492-1 / CE.
The Europull Electrical Winch's motor & Voltage: Heavy-Duty Induction Motor 380V/415V 3-Phase.
The Europull Electrical Winch's brake System: Fail-Safe Electromagnetic Drum / Disc Brake.
The Europull Electrical Winch's control: IP65 Pendant Control Station with Emergency Stop.
Click "Request a Quote" on this page to add the Electrical Winch to your quote cart, or email info@europull.com with the model code and quantity you need.
