Europull Manual Push Trolley
Europull EPPT manual push plain trolley designed for smooth manual traversing of hoists on I-beams, H-beams, and universal columns in compliance with EN 13157.
- Capacity0.5t - 10t
- Beam Width64mm - 305mm Adjustable
Need sizing help? Email info@europull.com
- Certified to EN 13157
- 6 models available
Technical Specifications
Model-by-model data for the Europull Manual Push Trolley range.
| Model Code | Capacity (Tons) | Flange Width (mm) | Min Curve Radius (m) | Proof Load (kN) | Net Weight (kg) |
|---|---|---|---|---|---|
| EPPT-005 | 0.5 Ton (500 kg) | 64 - 152 mm | 0.8 m | 7.5 kN | 6.0 kg |
| EPPT-010 | 1.0 Ton (1,000 kg) | 64 - 203 mm | 1.0 m | 15.0 kN | 10.5 kg |
| EPPT-020 | 2.0 Ton (2,000 kg) | 88 - 203 mm | 1.1 m | 30.0 kN | 15.0 kg |
| EPPT-030 | 3.0 Ton (3,000 kg) | 102 - 305 mm | 1.3 m | 45.0 kN | 26.0 kg |
| EPPT-050 | 5.0 Ton (5,000 kg) | 114 - 305 mm | 1.5 m | 75.0 kN | 42.0 kg |
| EPPT-100 | 10.0 Ton (10,000 kg) | 125 - 305 mm | 2.0 m | 150.0 kN | 88.0 kg |
Need a model or configuration not listed? Email our engineering team or download the full catalog (PDF).
Key Parameters
| Parameter | Specification | Highlight |
|---|---|---|
| Standard / Norms | EN 13157 / CE Certified | Certified |
| Rated Capacity | 0.5 Ton to 10 Ton | 0.5t - 10t |
| Flange Width Range | 64 mm to 305 mm (Adjustable with Spacers) | Universal Fit |
| Wheels & Bearings | Dual Flange Machined Cast Steel Wheels with Sealed Bearings | Smooth Roll |
| Safety Features | Anti-Drop Plates and Integrated Wheel Bumpers | Fail-Safe |
| Safety Factor | 4:1 Working Safety Margin | 1.5x Proof Load |
| Finish | Industrial Powder Coated / Anti-Corrosion | Long Life |
Key Features & Advantages
Smooth Rolling Wheels
Precision machined crowned wheels operate smoothly on both flat and tapered beam flanges.
Anti-Drop Plates
Integrated structural side plate guards prevent trolley wheel derailment.
Quick Spacing Adjustment
Easily adjusted to wide or narrow beam sizes by rearranging washer spacers.
Standards & Compliance
EN 13157 Compliance
Standard for hand powered overhead trolleys.
CE Certified
150% proof load tested with certificate.
Product Overview
The Europull EPPT plain push trolley provides effortless lateral travel along overhead structural beams. Perfect for maintenance bays, light crane runways, and assembly lines.
Frequently Asked Questions
The Europull Manual Push Trolley is available in 6 models: EPPT-005, EPPT-010, EPPT-020, EPPT-030, EPPT-050, EPPT-100. Capacity (Tons) ranges from 0.5 Ton (500 kg) to 10.0 Ton (10,000 kg). Full figures for every model are in the technical specifications table on this page.
The Europull Manual Push Trolley covers 0.5t - 10t.
The Europull Manual Push Trolley is manufactured to EN 13157.
The Europull Manual Push Trolley's flange Width Range: 64 mm to 305 mm (Adjustable with Spacers).
The Europull Manual Push Trolley's wheels & Bearings: Dual Flange Machined Cast Steel Wheels with Sealed Bearings.
The Europull Manual Push Trolley's safety Features: Anti-Drop Plates and Integrated Wheel Bumpers.
Click "Request a Quote" on this page to add the Manual Push Trolley to your quote cart, or email info@europull.com with the model code and quantity you need.
