Europull Wire Rope Clip U Bolt Type
Heavy-duty drop-forged carbon steel U-bolt wire rope clip (cable clamp) manufactured to DIN 741 / US Federal Specification for secure loop terminations.
- MaterialForged Carbon Steel / Malleable Iron
Need sizing help? Email info@europull.com
- Certified to DIN 741 / US Fed. Spec.
- 8 models available
Technical Specifications
Model-by-model data for the Europull Wire Rope Clip U Bolt Type range.
| Rope Dia (mm) | Rope Dia (in) | Thread Size | Min Clips Required | Torque (Nm) | Weight (kg/100) |
|---|---|---|---|---|---|
| 5 mm | 3/16" | M5 | 3 clips | 4.0 Nm | 2.1 kg |
| 6.5 mm | 1/4" | M6 | 3 clips | 6.5 Nm | 4.0 kg |
| 8 mm | 5/16" | M8 | 3 clips | 15.0 Nm | 8.2 kg |
| 10 mm | 3/8" | M8 | 3 clips | 20.0 Nm | 9.2 kg |
| 12 mm | 1/2" | M10 | 4 clips | 33.0 Nm | 21.0 kg |
| 16 mm | 5/8" | M12 | 4 clips | 49.0 Nm | 28.0 kg |
| 20 mm | 3/4" | M12 | 5 clips | 68.0 Nm | 40.0 kg |
| 26 mm | 1" | M16 | 6 clips | 140.0 Nm | 80.0 kg |
Need a model or configuration not listed? Email our engineering team or download the full catalog (PDF).
Key Parameters
| Parameter | Specification | Highlight |
|---|---|---|
| Standard / Specs | DIN 741 / US Fed. Spec. FF-C-450 | Certified |
| Rope Size Range | 3 mm to 40 mm (1/8" to 1-1/2") | Full Range |
| Material | Drop-Forged Steel Saddle with High-Tensile U-Bolt | Heavy Duty |
| Finish | Electro-Galvanized / Hot Dip Galvanized | Rust Proof |
| Efficiency | Up to 80-90% of Wire Rope Breaking Strength | High Hold |
Key Features & Advantages
Deep Grooved Saddle
Grooved base matches wire rope lay to maximize frictional clamping grip.
Precision Cut Threads
Allows accurate torque tightening to recommended engineering standards.
Standards & Compliance
DIN 741 / US Fed. Spec. FF-C-450
Wire rope termination standards.
CE Verified
Quality proof tested.
Product Overview
Europull U-bolt wire rope clips provide secure, reliable field termination and eye-loop creation for steel wire ropes across cranes, winches, guy wires, and barriers.
Frequently Asked Questions
The Europull Wire Rope Clip U Bolt Type is available in 8 models: 5 mm, 6.5 mm, 8 mm, 10 mm, 12 mm, 16 mm, 20 mm, 26 mm. Rope Dia (in) ranges from 3/16" to 1". Full figures for every model are in the technical specifications table on this page.
The Europull Wire Rope Clip U Bolt Type is manufactured to DIN 741 / US Fed. Spec..
The Europull Wire Rope Clip U Bolt Type's rope Size Range: 3 mm to 40 mm (1/8" to 1-1/2").
The Europull Wire Rope Clip U Bolt Type's material: Drop-Forged Steel Saddle with High-Tensile U-Bolt.
The Europull Wire Rope Clip U Bolt Type's finish: Electro-Galvanized / Hot Dip Galvanized.
Click "Request a Quote" on this page to add the Wire Rope Clip U Bolt Type to your quote cart, or email info@europull.com with the model code and quantity you need.
